Specification

StyleSpin-On Filter
Efficiency 110µ @ β2
Outer Diameter 128.0 mm
Length 182.0 mm
Thread1 1/4" BSP
Bypass Pressure 1.7 BAR
MediaCellulose
Δ Collapse Pressure 12 BAR
Seal MaterialNitrile
Temperature Range -30 - +100°C

Original Fleetguard Product

We Guarantee This Fleetguard HF6326 Is

  • Made by Fleetguard, Supplied by Us.
  • Fully Inspected in Accordance with ISO 9001:2015.

What This Means For You

  • Simple No Quibble 45 Day Returns.
  • 1 Year Manufacturer Warranty.
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
10µ @ β2
Efficiency 2
Style Spin-On Filter
Outer Diameter 128.0 mm
Inner Diameter
Length 182.0 mm
Media Type Cellulose
Flow Direction
Thread 1 1/4" BSP
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

1.7 BAR
Collapse Pressure 12 BAR
Seal Nitrile
Temperature Range -30 - +100°C
