UFI ERA32NCD Replaces the Donaldson 48153

UFI ERA32NCD
UFI ERA32NCD

UFI ERA32NCD Replaces the Donaldson 48153

ERA32NCD
UFI
Donaldson 48153
Brand: UFI
Sort by:
Description

Original UFI ERA32NCD replacement filter.

Price Matched
€15,95
Price€15,95/each
Shipped Monday, 19 May
UNITSPER UNIT
2 - 4€15,64
5 - 9€15,32
10 - + €15,00
8421.99.90
Italy
Shipping Terms

Description

Original UFI ERA32NCD replacement filter.

Specification

StylePressure Filter
Efficiency 120µ @ β200
Efficiency 222µ @ β1000
Outer Diameter 47.0 mm
Inner Diameter 22.4 mm
Length 84.0 mm
MediaGlass Fiber
Flow DirectionOUT-IN
Δ Collapse Pressure 20 BAR
Seal MaterialNitrile
Temperature Range -30 - +100°C

Approved Product

Find out more
Donaldson Brand Logo

Same Fit-Form & Function

As the Genuine Donaldson 48153

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
20µ @ β200
Efficiency 2 22µ @ β1000
Style Pressure Filter
Outer Diameter 47.0 mm
Inner Diameter 22.4 mm
Length 84.0 mm
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 20 BAR
Seal Nitrile
Temperature Range -30 - +100°C
